Grandstream 24 Port PoE L2+ Managed Switch

The Grandstream 24 Port PoE L2+ Managed Switch allows small-to-medium enterprises to build scalable, secure, high performance, and smart business networks that are fully manageable. It supports advanced VLAN for flexible and sophisticated traffic segmentation, advanced QoS for prioritization of network traffic, IGMP Snooping for network performance optimization, and comprehensive security capabilities against potential attacks.

Provides smart dynamic PoE output to power IP phones, IP cameras, Wi-Fi access points and other PoE endpoints. The Grandstream GWN7803P switch can be managed in a number of ways, including the local web user interface of the GWN7803P switch. The series is also supported by GWN.Cloud and GWN Manager, Grandstreams cloud and on-premise Wi-Fi management platform. The enterprise-grade GWN7800 series are the ideal managed network switches for small-to-medium businesses

Features of The Grandstream Enterprise 24 Port PoE L2+ Managed Switch

• 24 x Gigabit Ethernet ports and 4 Gigabit SFP ports
• Smart power control to support dynamic PoE/PoE+ power allocation per port
• Supports deployment in IPv6 and IPv4 networks
• Provides quaternary binding of IP, MAC, VLAN & port; ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
• Local Web UI to manage switch, GWN.Cloud and GWN Manager, Grandstreams cloud and on-premise Wi-Fi management platform
• Built-in QoS allows for prioritization of network traffic.

Specifications:

• Gigabit Ethernet Ports: 24
• Gigabit SFP Ports: 4
• Console Port: Yes
• # of PoE Ports: 24
• Integrated Power Supply: 400W
• Max Output Power per PoE Port: 30W
• Max Total PoE Output Power: 360W
• PoE Standards: IEEE 802.3af/at
• Multicast: IGMP Snooping, MLD Snooping, MVR
• DHCP: DHCP server, DHCP relay, Option 82, 60,160 and 43
• Maintenance: CPU & memory monitoring, SNMP, RMON, LLDP&LLDP-MED, backup & restore, syslog, alert, diagnostics including Ping, Traceroute, port mirroring, UDLD(TBD) & copper test
• Mounting: Desktop, wall-mount, or rack-mount (rack-mount brackets included)
• Fan: 2

Switching:

• 8K static, dynamic and filtering MAC addresses
• 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN
• VLAN virtual interface
• GVRP (pending)
• 8 link aggregation groups
• Spanning tree, 16 instances for STP/RSTP/MSTP

QoS/ACL:
